Hogan Prime
| Test | isi requirment | observed value |
|---|---|---|
| Moisture content | 5% – 15% | 8% |
| Sheer Strenght (Dry State) | Min. Ind. 1100 N Min. Avg. 1350 N |
1350 N 1500 N |
| Adhesioin To Plies | Minimum pass standard | Excellent |
| Sheer Strength (after 72 hrs boiling water) |
Min. Ind. 800 N Min. Avg. 1000 N |
1150 N 1250 N |
| Tensile Strength | ||
|---|---|---|
| -Along the grain -Acros the grain Sum of tensile strength |
4200 N/ sq.mm 2500 N/ sq.mm 8450 N/ sq.mm |
5500 N/ sq.mm 3950 N/ sq.mm 9400 N/ sq.mm |
| Static Bending Strength | ||
|---|---|---|
| a. Modulus of Rupture | ||
| -along the grain -along the grain |
50 N/ sq.mm 30 N/sq.mm |
65 N/ sq.mm 40 N/ sq.mm |
| Static Bending Strength | ||
|---|---|---|
| b. Modulus of elasticity | ||
| -alog the grain -acros the grain |
7500 N/ sq.mm 4000 N/sq.mm |
8305 N/ sq.mm 4170 N/ sq.mm |
